Planar Portable Diesel Heater

Regular price: $1,575.00
Sale price: $1,425.00

Shipping calculated at checkout.

Heat Output

Ducting

Color

Quantity

Quantity must be 1 or more

If you take the winter off from camping because it's too cold, then you definitely need one of these portable diesel heaters from Planar!

Unlike propane heaters, which will cause a build up of condensation, this Planar heater produces a dry heat. You'll be toasty warm and dry all night long.

Altitude Compensation

Unlike other heaters, these have an altitude-compensating feature built right into the unit that allows them to operate at higher altitudes. An on-board pressure sensor detects the current altitude and makes adjustments to the fuel pump in order to introduce the right amount of fuel for the conditions.

As a result, at altitudes above 6,500 ft sea level, performance will drop by roughly 5% every 1,640 ft.

For example, at 12,000 ft above sea level the heater output would be reduced by roughly 16.75%. At this altitude, this means a 2kw heater's output would be reduced to 1.6kw and a 4kw heater's output would be reduced to 3.3kw.

PLEASE NOTE:

The Planar manual states that the heater includes an extra fuel cap. It does not. The heater only comes with one.

The power cable supplied with the heater comes with ring terminals by default.

Signature is required for delivery.

If you don't want ring terminals, you will either need to replace the ring terminals yourself, or buy one of our adapters that can be used to interface with different power sources. These adapters require our custom 20' adapter-ready power cable, seen in the video below.

SPECS

2 kW version

Heat Output:	0.8 – 2.0 kW / 2,700-7,000 btu
Fuel Consumption:	0.10-0.24 l/h / 0.03-0.06 gal/h
Nominal Supply Voltage:	12V
Power Consumption; W (A):	10-29 w (0.8-2.42 A)
Airflow Rate:	34-75 m³/h
Weight:	11.6 kg. / 25.5 lb.
L x D x H:	324 x 118 x 119 mm. / 24 x 16.5 x 19 in
Operating Modes:	Temperature/Power

4 kW version

Heat Output:	1.0 – 4.0 kw / 3,400-13,600 btu
Fuel Consumption:	0.12-0.51 l/h / 0.03-0.14 gal/h
Nominal Supply Voltage:	12V
Power Consumption; W (A):	10-57 w (0.8-4.75 A)
Airflow Rate:	70-168 m³/h
Weight:	15 kg. / 33 lb.
L x D x H:	635 x 483 x 483 mm. / 25 x 19 x 19 in
Operating Modes:	Power

Warranty

2 Years

Works but has major flaws

We have been traveling full-time for 9 months now and for the entirety of this time we have been using the planar heater.

First off the good things:
- when it works, it keeps you warm
- the heat is a dry heat, so you don’t have to deal with the negative effects of condensation

Now the negative things:
- you cannot run this heater for extended periods of time on diesel, you have to use the more expensive kerosene. If you use diesel for a prolonged time, the glow plug gets sooted up and the heater will not turn on. Even regular (as in daily) cleaning will not prevent this.
- You cannot use the heater for an extended period of time on low setting. The glow plug will soot up and you will have the same issue as above.
- Be aware that the tank will leak which is especially annoying when you drive it around in your car or camper. Even if you keep the kerosene level in the tank very low as you are driving over bumpy roads it will leak. We have started putting cardboard and towels underneath it so it does not spill everywhere.

Have not used yet

Have not used yet . Shipping was quick I did have to pay duty from Canada . All accessories ordered arrived timely. Will write a full review when I put it to some use. Have purchased other things from this company and shipping was fast. I will continue to purchase things from this company. Full review to follow later

Diesel Heater

Fantastic from start to finish. Team at Overland answered all of my questions and the heater worked great during a two night outing in March.

Great heater

Heated are smittybilt xl tent easily in 0 degrees

Quality Unit

Everything was as advertised. Its built like a tank and runs forever on very little fuel. Very happy with the portability and the amount of heat that gets put out.
